DECS-250 Mounting
17 • Mounting
As delivered, the DECS-250 is configured for projection (wall) mounting. Front panel mounting is possible
with an optional escutcheon kit. Kits are supplied with an escutcheon and screws for securing the
escutcheon to the DECS-250. Request part number 9440311101. This kit is suitable for new installations
and when replacing a DECS-200 with the DECS-250.
Mounting Considerations
DECS-250 heat sink orientation necessitates vertical mounting for maximum cooling. Any other mounting
angle will reduce heat dissipation and possibly lead to premature failure of critical components.
The DECS-250 may be mounted anywhere the ambient temperature does not exceed the maximum
operating temperature as listed in the Specifications chapter.
This device is not intended for exposure to caustic environments. If operated
in such an environment, the device must be housed in an enclosure that
shields it from exposure to all caustic elements.
Projection Mounting
Figure 17-1 illustrates the mounting dimensions for projection (wall) mounting of the DECS-250.
Behind-the-Panel Mounting
Figure 17-2 shows the front dimensions of the optional escutcheon mounting plate for the DECS-250.
Panel cutting and drilling dimensions for panel mounting are shown in Figure 17-3.
