9440300990 32-1
DECS-250 Analog Expansion Module
32 • Analog Expansion Module
General Information
The optional AEM-2020 is a remote auxiliary device that provides additional DECS-250 analog inputs and
outputs.
Features
The AEM-2020 has the following features:
• Eight Analog Inputs
• Eight RTD Inputs
• Two Thermocouple Inputs
• Four Analog Outputs
• Functionality of Inputs and Outputs assigned by BESTlogic™Plus programmable logic
• Communications via CAN Bus
Specifications
Operating Power
Nominal ...................................... 12 or 24 Vdc
Range ......................................... 8 to 32 Vdc (Withstands ride-through down to 6 Vdc for 500 ms.)
Maximum Consumption ............. 5.1 W
Analog Inputs
The AEM-2020 contains eight programmable analog inputs.
Rating ......................................... 4 to 20 mA or 0 to 10 Vdc (user-selectable)
Burden
4 to 20 mA ........................... 470 Ω maximum
0 to 10 Vdc ........................... 9.65k Ω minimum
RTD Inputs
The AEM-2020 contains eight programmable RTD inputs.
Rating ......................................... 100 Ω Platinum or 10 Ω Copper (user-selectable)
Setting Range ............................ –50 to +250°C or –58 to +482°F
Accuracy (10 Ω Copper) ............. ±0.044 Ω @ 25°C, ±0.005 Ω/°C drift over ambient temperature
Accuracy (100 Ω Platinum) ......... ±0.39 Ω @ 25°C, ±0.047Ω/°C drift over ambient temperature
Thermocouple Inputs
The AEM-2020 contains two thermocouple inputs.
Rating ......................................... 2 K Type Thermocouples
Setting Range ............................ 0 to 1,375°C or 0 to 2,507°F
Display Range ............................ Ambient to 1,375°C or Ambient to 2,507°F
Accuracy..................................... ±40uV @ 25°C, ±5 uV/°C drift over ambient temperature
Analog Outputs
The AEM-2020 contains four programmable analog outputs.
Rating ......................................... 4 to 20 mA or 0 to 10 Vdc (user-selectable)
