DECS-250 CAN Communication
27 • CAN Communication
Introduction
CAN Bus interface 1 facilitates communication between the DECS-250 and optional modules such as the
Contact Expansion Module (CEM-2020) and Analog Expansion Module (AEM-2020). Refer to the
chapters Contact Expansion Module and Analog Expansion Module for more information.
CAN Bus interface 2 enables the DECS-250 to provide generator and system parameters to a generator
controller such as the Basler DGC-2020. CAN 2 also permits DECS-250 setpoint and mode control from
an external device connected to the CAN. The parameters sent over CAN 2 are listed in this chapter.
Both CAN Bus interfaces utilize the SAE J1939 messaging protocol.
Refer to the Communication chapter for CAN port configuration and the Terminals and Connectors
chapter for wiring.
CAN Parameters
Supported CAN parameters are listed in Table 27-1. The first column contains the parameter group
number (PGN), the second column contains the parameter name, the third column contains the unit of
measurement for a parameter, the fourth column contains the suspect parameter number (SPN), and the
fifth column contains the broadcast rate for a parameter.
Table 27-1. CAN Parameters
PGN Name Units SPN
Broadcast
Rate
0xFDA6 Generator Excitation Field Voltage Volts 3380 100 ms
Generator Excitation Field Current Amps 3381
Generator Output Voltage Bias Percentage Percent 3382
0xFDA7 Voltage Regulator Load Compensation Mode n/a 3375 1 s
Voltage Regulator var/PF Operating Mode
n/a
3376
Voltage Regulator Underfrequency Compensation Enabled n/a 3377
Voltage Regulator Soft Start State n/a 3378
Voltage Regulator Enabled n/a 3379
0xFDFD Generator Phase CA L-L AC RMS Voltage Volts 2443 100 ms
(Unsupported) n/a 2247
Generator Phase C AC RMS Current Amps 2451
0xFE00 Generator Phase BC L-L AC RMS Voltage Volts 2442 100 ms
(Unsupported) n/a 2446
Generator Phase B AC RMS Current Amps 2450
0xFE03 Generator Phase AB L-L AC RMS Voltage Volts 2441 100 ms
(Unsupported) n/a 2445
Generator Phase A AC RMS Current Amps 2249
0xFE06 Generator Average L-L AC RMS Voltage Volts 2440 100 ms
(Unsupported) n/a 2444
Generator Average AC Frequency Hertz 2436
Generator Average AC RMS Current Amps 2448
0xFE04 Generator Total Reactive Power var 2456 100 ms
Generator Overall PF n/a 2464
Generator Overall PF Lagging n/a 2518
0xFE05 Generator Total Real Power Watts 2452 100 ms
