Basler DECS-250 - Page 258

28-30 9440300990
Modbus
®
Communication DECS-250
Name
Register
Type
Bytes
R/W
Unit
Range
OEL Secondary Takeover Reset Type On
41886
Uint32
4
R W
n/a
Inverse=0
Integrating=1
Instantaneous=2
Setpoints
Table 28-10. Setpoint Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Field Current Regulation Setpoint
42200
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 42212 and 42214.
Field Current Regulation Traverse Rate
42202
Float
4
R W
Second
10–200
Field Current Regulation Pre-position
Mode 1
42204
Uint32
4
R W
n/a
Maintain=0 Release=1
Field Current Regulation Pre-position 1
42206
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 42212 and 42214.
Field Current Regulation Pre-position
Mode 2
42208
Uint32
4
R W
n/a
Maintain=0 Release=1
Field Current Regulation Pre-position 2
42210
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 42212 and 42214.
Field Current Regulation Minimum
Setpoint Limit
42212
Float
4
R W
Percent
0–120
Field Current Regulation Maximum
Setpoint Limit
42214
Float
4
R W
Percent
0–120
Generator Voltage Setpoint
42216
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 42228 and 42230.
Generator Voltage Traverse Rate
42218
Float
4
R W
Second
10–200
Generator Voltage Pre-position Mode 1
42220
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator Voltage Pre-position 1
42222
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 42228 and 42230.
Generator Voltage Pre-position Mode 2
42224
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator Voltage Pre-position 2
42226
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 42228 and 42230.
Generator Voltage Minimum Setpoint
Limit
42228
Float
4
R W
Percent
70–120
Generator Voltage Maximum Setpoint
Limit
42230
Float
4
R W
Percent
70–120
Generator var Setpoint
42232
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 42244 and 42246.
Generator var Traverse Rate
42234
Float
4
R W
Second
10–200
Generator var Pre-position Mode 1
42236
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator var Pre-position 1
42238
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 42244 and 42246.
Generator var Pre-position Mode 2
42240
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator var Pre-position 2
42242
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 42244 and 42246.
Generator var Minimum Setpoint Limit
42244
Float
4
R W
Percent
-100 – 100
Generator var Maximum Setpoint Limit
42246
Float
4
R W
Percent
-100 – 100
Generator PF Setpoint
42248
Float
4
R W
Power Factor
Setpoint adjustment range determined
by registers 42260 and 42262.
Generator PF Traverse Rate
42250
Float
4
R W
Second
10–200
Generator PF Pre-position Mode 1
42252
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator PF Pre-position 1
42254
Float
4
R W
Power Factor
Setpoint adjustment range determined
by registers 42260 and 42262.
Generator PF Pre-position Mode 2
42256
Uint32
4
R W
n/a
Maintain=0 Release=1
Generator PF Pre-position 2
42258
Float
4
R W
Power Factor
Setpoint adjustment range determined
by registers 42260 and 42262.
Generator PF Minimum Setpoint Limit
42260
Float
4
R W
Power Factor
0.5–1
Generator PF Maximum Setpoint Limit
42262
Float
4
R W
Power Factor
-1 – -0.5
FVR Setpoint
42264
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 42276 and 42278.
