Basler DECS-250 User Manual

28-46 9440300990
Modbus
®
Communication DECS-250
Name
Register
Type
Bytes
R/W
Unit
Range
Secondary AVR Mode Derivative Gain -
Kd
47899
Float
4
R W
n/a
0–1000
Secondary AVR Mode Loop Gain - Kg
47901
Float
4
R W
n/a
0–1000
Secondary AVR Derivative Time
Constant - Td
47903
Float
4
R W
n/a
0–1
Active Gain Setting Group
47905
Uint16
2
R
n/a
n/a
SCL Loop Gain - Kg
47906
Float
4
R W
n/a
0–1000
SCL Integral Gain - Ki
47908
Float
4
R W
n/a
0–1000
Reserved 14
47910-920
C9
Filler
22
n/a
n/a
n/a
Field Overvoltage Level
47921
Float
4
R W
Volt
Disabled=0, 1–325
Field Overcurrent Base Level
47923
Float
4
R W
Amp
Disabled=0, 0–22
Stator Undervoltage Level
47925
Float
4
R W
Volt
Disabled=0, 1–600000
Stator Overvoltage Level
47927
Float
4
R W
Volt
Disabled=0, 0–600000
Field Overvoltage Delay
47929
Float
4
R W
Millisecond
Disabled=0, 200–30000
Overcurrent Delay
47931
Float
4
R W
Millisecond
Disabled=0, 5000–60000
Stator Undervoltage Delay
47933
Float
4
R W
Millisecond
100–60000
Stator Overvoltage Delay
47935
Float
4
R W
Millisecond
100–60000
Field Overvoltage Alarm Enable
47937
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Field Overcurrent Alarm Enable
47938
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Stator Undervoltage Alarm Enable
47939
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Stator Overvoltage Alarm Enable
47940
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Reserved 15
47941
Float
4
R
n/a
n/a
Reserved 16
47943
Float
4
R
n/a
n/a
Reserved 17
47945
Uint16
2
R
n/a
n/a
Exciter Open Diode Ripple Pickup Level
47946
Float
4
R W
Percent
0 - 100
Exciter Open Diode Time Delay
47948
Float
4
R W
Second
10–60
Exciter Open Diode Protection Enable
47950
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Exciter Shorted Diode Ripple Pickup
Level
47951
Float
4
R W
Percent
0–100
Exciter Shorted Diode Time Delay
47953
Float
4
R W
Second
5–30
Exciter Shorted Diode Protection Enable
47955
Uint16
2
R W
n/a
Disabled=0 Enabled=1
EDM Protection Disable Level
47956
Float
4
R W
Percent
0–100
Loss of Field Alarm Enable
47958
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Loss of Field Pickup Level
47959
Float
4
R W
Percent
Disabled=0, 0–150
Loss of Field Time Delay
47961
Float
4
R W
Millisecond
Instantaneous=0, 0–300000
Reserved 18
47963-980
C10
Filler
36
n/a
n/a
n/a
Reserved 19
47981-8040
C11
Filler
120
n/a
n/a
n/a
Reserved 16 bit 1
48041
Uint16
2
R W
n/a
0–65535
Reserved 16 bit 2
48042
Uint16
2
R W
n/a
0–65535
Reserved 20
48043-056
Annun
Filler
28
R
n/a
n/a
Output for Relay 1
48057
Uint16
2
R
n/a
n/a
Reserved
48058-76
Uint16
2
R W
n/a
0–65535
Output for Relay 2
48077
Uint16
2
R
n/a
n/a
Reserved
48078-96
Uint16
2
R W
n/a
0–65535
Output for Relay 3
48097
Uint16
2
R
n/a
n/a
Reserved 16 bit 13
48098-116
Uint16
2
R W
n/a
0–65535
Output for Relay 4
48117
Uint16
2
R
n/a
n/a
Reserved 16 bit 18
48118-136
Uint16
2
R W
n/a
0–65535
Output for Relay 5
48137
Uint16
2
R
n/a
n/a
Reserved 16 bit 23
48138-141
Uint16
2
R W
n/a
0–65535
