Basler DECS-250 - Page 323

9440300990 29-47
DECS-250 PROFIBUS Communication
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Remote Analog Out 1
240
Float
R/W
Current Max GG
mA
4 - 20
Remote Analog Out 1
240
Float
R/W
Voltage Min GG
V
0 - 10
Remote Analog Out 1
240
Float
R/W
Voltage Max GG
V
0 - 10
Remote Analog Out 2
241
UINT32
R/W
Param Selection GG
No Unit
Gen VAB=0 Gen VBC=1 Gen
VCA=2 Gen V Average=3 Bus
Freq=4 Bus VAB=5 Bus VBC=6
Bus VCA=7 Gen Freq=8 Gen PF=9
KWH=10 KVARH=11 Gen IA=12
Gen IB=13 Gen IC=14 Gen I
Average=15 KW Total=16 KVA
Total=17 KVAR Total=18 EDM
Ripple=19 Exciter Field Voltage=20
Exciter Field Current=21 Auxiliary
Input Voltage=22 Auxiliary Input
Current (mA)=23 Setpoint
Position=24 Tracking Error=25 Neg
Seq V=26 Neg Seq I=27 Pos Seq
V=28 Pos Seq I=29 PSS
Output=30 Analog Input 1=31
Analog Input 2=32 Analog Input
3=33 Analog Input 4=34 Analog
Input 5=35 Analog Input 6=36
Analog Input 7=37 Analog Input
8=38 RTD Input 1=39 RTD Input
2=40 RTD Input 3=41 RTD Input
4=42 RTD Input 5=43 RTD Input
6=44 RTD Input 7=45 RTD Input
8=46 Thermocouple 1=47
Thermocouple 2=48
Remote Analog Out 2
241
UINT32
R/W
Output Type GG
No Unit
Voltage=0 Current=1
Remote Analog Out 2
242
Float
R/W
Out of Range
Activation Delay GG
Sec
0 - 300
Remote Analog Out 2
242
Float
R/W
Param Min GG
No Unit
-99999 - 99999
Remote Analog Out 2
242
Float
R/W
Param Max GG
No Unit
-99999 - 99999
Remote Analog Out 2
242
Float
R/W
Current Min GG
mA
4 - 20
Remote Analog Out 2
242
Float
R/W
Current Max GG
mA
4 - 20
Remote Analog Out 2
242
Float
R/W
Voltage Min GG
V
0 - 10
Remote Analog Out 2
242
Float
R/W
Voltage Max GG
V
0 - 10
Remote Analog Out 3
243
UINT32
R/W
Param Selection GG
No Unit
Gen VAB=0 Gen VBC=1 Gen
VCA=2 Gen V Average=3 Bus
Freq=4 Bus VAB=5 Bus VBC=6
Bus VCA=7 Gen Freq=8 Gen PF=9
KWH=10 KVARH=11 Gen IA=12
Gen IB=13 Gen IC=14 Gen I
Average=15 KW Total=16 KVA
Total=17 KVAR Total=18 EDM
Ripple=19 Exciter Field Voltage=20
Exciter Field Current=21 Auxiliary
Input Voltage=22 Auxiliary Input
Current (mA)=23 Setpoint
Position=24 Tracking Error=25 Neg
Seq V=26 Neg Seq I=27 Pos Seq
V=28 Pos Seq I=29 PSS
Output=30 Analog Input 1=31
Analog Input 2=32 Analog Input
3=33 Analog Input 4=34 Analog
Input 5=35 Analog Input 6=36
Analog Input 7=37 Analog Input
8=38 RTD Input 1=39 RTD Input
2=40 RTD Input 3=41 RTD Input
4=42 RTD Input 5=43 RTD Input
6=44 RTD Input 7=45 RTD Input
8=46 Thermocouple 1=47
Thermocouple 2=48
Remote Analog Out 3
243
UINT32
R/W
Output Type GG
No Unit
Voltage=0 Current=1
Remote Analog Out 3
244
Float
R/W
Out of Range
Activation Delay GG
Sec
0 - 300
Remote Analog Out 3
244
Float
R/W
Param Min GG
No Unit
-99999 - 99999
Remote Analog Out 3
244
Float
R/W
Param Max GG
No Unit
-99999 - 99999
Remote Analog Out 3
244
Float
R/W
Current Min GG
mA
4 - 20
