9440300990 32-3
DECS-250 Analog Expansion Module
CE Compliance
This product complies with the requirements of the following EC Directives:
• Low Voltage Directive (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Hazardous Substances (RoHS 2) 2011/65/EU
This product conforms to the following Harmonized Standards:
• EN 50178:1997 - Electronic Equipment for use in Power Installations
• EN 61000-6-4:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Emission Standard
for Industrial Environments
• EN 61000-6-2:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Immunity for
Industrial Environments
• EN 50581:2012, Ed. 12 - Technical Documentation for the Assessment of Electrical and Electronic
Products with respect to the Restriction of Hazardous Substances.
EAC Mark (Eurasian Conformity)
• TP TC 004/2011
• TP TC 020/2011
Physical
Weight ........................................ 1.80 lb (816 g)
Dimensions................................. See Installation later in this chapter.
Installation
Analog Expansion Modules are delivered in sturdy cartons to prevent shipping damage. Upon receipt of a
module, check the part number against the requisition and packing list for agreement. Inspect for
damage, and if there is evidence of such, immediately file a claim with the carrier and notify the Basler
Electric regional sales office, your sales representative, or a sales representative at Basler Electric,
Highland, Illinois USA.
If the device is not installed immediately, store it in the original shipping package in a moisture- and dust-
free environment.
Mounting
Analog Expansion Modules are contained in a potted plastic case and may be mounted in any convenient
position. The construction of an Analog Expansion Module is durable enough to mount directly on a
genset using ¼-inch hardware. Hardware selection should be based on any expected
shipping/transportation and operating conditions. The torque applied to the mounting hardware should not
exceed 65 in-lb (7.34 N•m).
See Figure 32-1 for AEM-2020 overall dimensions. All dimensions are shown in inches with millimeters in
parenthesis.
