Specification scA750-60fm/fc scA780-54fm/fc scA1000-20fm/fc
Sensor Size
(H x V pixels)
fm: 752 x 480
fc: 750 x 480
fm: 782 x 582
fc: 780 x 580
fm: 1034 x 779
fc: 1032 x 778
Sensor Type Aptina MT9V022 (formerly
known as the
Micron MT9V022)
Sony ICX415 AL/AQ Sony ICX204 AL/AK
Progressive Scan CMOS Progressive scan CCD
Optical Size 1/3" 1/2" 1/3"
Pixel Size 6.0 µm x 6.0 µm 8.3 µm x 8.3 µm 4.65 µm x 4.65 µm
Max. Frame Rate
(at full resolution
64.9 fps 58 fps 21 fps
Mono/Color All models available in mono or color
Data Output Type IEEE 1394b
Pixel Data Formats Mono Models:
Mono 8 ( = DCAM Mono
8)
YUV 4:2:2 Packed
( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV)
Packed
Mono 8 ( = DCAM Mono 8)
Mono 16 ( = DCAM Mono 16)
Mono 12 Packed
YUV 4:2:2 Packed ( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8 ( = DCAM Mono
8)
Bayer RG 8 ( = DCAM
Raw 8)
YUV 4:2:2 Packed
( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV)
Packed
Mono 8 ( = DCAM Mono 8)
Bayer BG 8 ( = DCAM Raw 8)
Bayer BG 16 ( = DCAM Raw 16)
Bayer BG 12 Packed
YUV 4:2:2 Packed ( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 10 bits 12 bits
Synchronization Via external trigger signal or via software
Exposure Control Programmable via the camera API
Camera Power
Requirements
+ 8 to + 36 VDC supplied via the IEEE 1394 cable < 1% ripple
1.7 W @ 12 V 2.5 W @ 12 V
I/O Ports 2 opto-isolated input ports and 4 opto-isolated output ports
Lens Adapter C-mount (CS-mount optional)
