Specifications, Requirements, and Precautions
26 Basler scout
Fig. 22: Mechanical Dimensions (in mm) for Cameras with an Option CS-mount Lens Adapter
Top
12.5
Photosensitive
surface of the
sensor
2x M3; 3.5 deep
67.2
2x M3; 4.5 deep
4.7
Bottom
67.2
2x M3; 4 deep
4.7
2x M3; 4.5 deep
32
4.5
16
2x M3; 4.5 deep
12.5
80.5
73.7
72.3
1.45
44
