Fig. 25: Mechanical Dimensions (in mm) for Cameras (90° Head) with the Standard C-mount Lens Adapter
3.25
32.1
2 x M3; 4.5 Deep
3.25
51.15
3.75
2 x M3; 4 Deep
2 x M3; 4.8 Deep
32.1
15.6
3.1
12.9
12.85
2 x M3; 4.5 Deep
2 x M3; 4.5 Deep
97
91.65
72.65
Ø
28.5
29
Photosensitive
surface of the
sensor
86.3
2 x M3; 3.5 Deep
2 x M3; 4.5 Deep
Bottom
Top
