Functional Description
46 Basler scout
Fig. 28: CCD Sensor Architecture
Fig. 29: Camera Block Diagram
CCD Sensor
Vert.
Shift
Reg.
Vert.
Shift
Reg.
Vert.
Shift
Reg.
Vert.
Shift
Reg.
Pixels Pixels Pixels Pixels
Horizontal
Shift Register
ADC VGC
Sensor ADC FPGA
Link
Layer
Controller
Physical
Layer
Controller
24 MB
Buffer
Data
Data
I/O
ExTrig
e.g. ExpActive,
TrigRdy
Micro-
Controller
Control:
AOI, Gain, Black Level
Asynchronous
Data
Isochronous
and
Asynchronous
Data
Isochronous
and
Asynchronous
Data
IEEE
1394b
Bus
Data
Control
VGC
