Physical Interface
58 Basler scout
Voltage Levels When a PLC I/O Cable is Used
When a PLC I/O cable is used, the following voltage requirements apply to the inputs to the PLC
I/O cable. The PLC I/O cable will adjust the voltages to the levels required at the camera’s I/O input
(see the previous table).
Voltage Significance
+0 to +24 VDC Recommended operating voltage.
+0 to +8.4 VDC The voltage indicates a logical 0.
> +8.4 to
+10.4 VDC
Region where the transition threshold occurs; the logical state is not defined in this region.
> +10.4 VDC The voltage indicates a logical 1.
+30.0 VDC Absolute maximum; the camera may be damaged if the absolute maximum is exceeded.
Table 11: Voltage Requirements for the I/O Input When Using a PLC I/O Cable
