Batca Fitness Systems 16 Omega 4 Owner's Manual
Step 7:
Figure 7
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Item # Part # Description Qty
24 BFP-52138
Shroud With Logo
2
25
BFM-50444a
Shroud 2
90 BFP-52340 SHCS 3/8” x 3/4” 16
111 BFH-50146 3/8” Flat Washer 16
Please note the
position of the
Shroud with Logo and
make sure they are
positioned correctly and
are in the correct
location
