www.batcafitness.com 17 Omega 4 Owner’s Manual
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Step 8:
Item # Part # Description Qty
26 BFP-10844
Mid Row Arm
1
27 BFP-10846 Knee Hold Down 1
28 BFP-51800
Curved Anti-Deflection Plate
1
29 BFP-51776 Axle 1
79 BFP-51696 Small Aluminum End Cap 2
91 BFP-50620 BHSCS 3/8” x 1” 2
106 BFP-51756 SHCS 3/8” x 5 1/4” 2
110 BFH-50204 3/8” Curved Washer 4
112 BFH-50157 3/8” Nylock 2
Figure 8
To Next Page
