Batca Fitness Systems 18 Omega 4 Owner's Manual
Item # Part # Description Qty
30 BFP-10845 Swivel Pulley Holder 1
31 BFP-10955 Chest Chrome Adjusment 1
32 BFP-10967
Chrome Mid Row Seat Adjustment
1
80 BFH-50210 Gas Spring 1
81 BFH-50165 1” Snap Ring 2
88 BFP-52372 SHCS 5/16” x 1/2” 1
98 BFP-51752 SHCS 3/8” x 2 1/4” 1
100 BFP-51750 SHCS 3/8” x 2 3/4” 1
111 BFH-50146 3/8” Flat Washer 2
112 BFH-50157 3/8” Nylock 2
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Step 9:
Figure 9
Make sure this bolt goes
through the bottom and top
holes of the Gas Spring
To Next Page
