www.batcafitness.com 19 Omega 4 Owner’s Manual
All Flat Washers and Nylocks are 3/8”
unless otherwise noted.
Step 10:
Item # Part # Description Qty
33 BFP-10833
Pec Cam (Left)
1
34 BFP-10834 Pec Cam (Right) 1
35 BFP-10831 Upper Pec Arm (Left) 1
36 BFP-10830 Upper Pec Arm (Right) 1
37
BFP-10825rev1
Foot Assist 1
38 BFP-51699 Axle 1
79 BFP-51696 Small Aluminum End Cap 4
91 BFH-50620 BHSCS 3/8” x 1” 4
Figure 10
To Next Page
