7 Appendix
7.1 Overview max. rpm / switching frequency
Table 2: Overview encoder disk 2'048
Pulse disk Number of
pulses
max.
revolutions
(rpm)
max. switching frequency (Hz)
(05A output circuit)
2’048 2’048 6’000 250'000
2’048 4’096 6’000 500'000
2’048 8’192 6’000 1’000'000
2’048 16’384 4’763 1’300'000
2’048 32’768 2’380 1’300'000
2’048 65’536 1’190 1’300'000
2’048 131’072 595 1’300'000
Pulse disk Number of
pulses
max.
revolutions
(rpm)
max. switching frequency (Hz)
(24K output circuit)
2’048 2’048 6’000
250’000
2’048 4’096 4’394
300’000
2’048 8’192 2’197
300’000
2’048 16’384 1’100
300’000
2’048 32’768 549
300’000
2’048 65’536 279
300’000
2’048 131’072 137
300’000
Table 3: Overview encoder disk 5'000
Pulse disk Number of
pulses
max.
revolutions
(rpm)
max. switching frequency (Hz)
(05A output circuit)
5’000 5’000 3'000 250'000
5’000 10’000 3'000 500'000
5’000 20’000 3’000 1’000'000
5’000 40’000 1’950 1’300'000
5’000 80’000 975 1’300'000
5’000 160’000 488 1’300'000
5’000 320’000 244 1’300'000
Pulse disk Number of
pulses
max.
revolutions
(rpm)
max. switching frequency (Hz)
(24K output circuit)
5’000 5’000 3'000
250’000
5’000 10’000 1’800
300’000
5’000 20’000 900
300’000
5’000 40’000 450
300’000
5’000 80’000 225
300’000
5’000 160’000 112
300’000
5’000 320’000 56
300’000
