Baumer EXG03 User Manual

33
5.6. MessageChannel
The asynchronous message channel is described in the GigE Vision
®
standard and offers
the possibility of event signaling. There is a timestamp (64 bits) for each announced event,
which contains the accurate time the event occurred. Each event can be activated and
deactivated separately.
5.6.1. EventGeneration
Event Description
Gen<i>Cam™
ExposureStart Exposure started
ExposureEnd Exposure ended
FrameStart Acquisition of a frame started
FrameEnd Acquisition of a frame ended
Line0Rising Rising edge detected on IO-Line 0
Line0Falling Falling edge detected on IO-Line 0
Line1Rising Rising edge detected on IO-Line 1
Line1Falling Falling edge detected on IO-Line 1
Line2Rising Rising edge detected on IO-Line 2
Line2Falling Falling edge detected on IO-Line 2
Line3Rising Rising edge detected on IO-Line 3
Line3Falling Falling edge detected on IO-Line 3
Line4Rising Rising edge detected on IO-Line 4
Line4Falling Falling edge detected on IO-Line 4
Line5Rising Rising edge detected on IO-Line 5
Line5Falling Falling edge detected on IO-Line 5
Vendor-specic
EventError Error in event handling
EventLost Occured event not analyzed
TemperatureExceeded Reference value of temperature exceeded
TriggerReady t
notready
(see chapter 2.4) elapsed, camera is able to
process incoming trigger
TriggerOverlapped Overlapped Mode (see chapter 2.4) detected
TriggerSkipped Camera overtriggered (see chapter 2.4)
By the individual cameras of the Baumer EXG series the GigE Vision
®
Mes-
sage Channel is supported in different degrees.
