Programming lines / overview
Line Short description Programming field 1
01
02
03
04
05
06
07
08
XP - Main counter status
P1 - Preset value P1
P2 - Preset value P2
SC - Main counter start count value
∑ - Totalizing counter
XB - Batch counter status
B1 - Batch counter preset value
- Time meter
10 Separating line Programming field 2
11
12
13
14
15
16
17
18
STAT - XP - Main counter status
STAT - P1 - Preset value P1
STAT - P2 - Preset value P2
STAT - SC - Main counter start count value
STAT - ∑ - Totalizing counter
STAT - XB - Batch counter status
STAT - B1 - Batch counter preset value
STAT -
- Time meter
20 Separating line Programming field 3
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
Operating modes, main counter
Scaling factor, main counter
Multiplier, batch counter
Frequency, main counter, track A
Frequency, main counter, track B
Frequency, batch counter XB
Counting mode XP and ∑
Decimal point (applies to XP, P1, P2, SC, ∑)
Reset, main counter
Reset, batch counter
Output time P1
Output time P2
Output time B1
Accept presets P1, P2, B1
Adresses for function key F
Batch counter XB functions
Pulses per unit of measurement as tacho
Input of time measurement in seconds (s)
Assignment output B1
Function input XP stop
Code setting
42 Separating line Programming field 4
43
44
45
46
Baud rate
Parity
Adress
Stop bits
47 Separating line
