6.2 Default settings
The device is supplied programmed with the following default para-
meters:
P1 limit value 1 1000
P2 limit value 2 2000
Measurement function Ratio F1:F2
Signal type at F1 One track (up/down)
Input logic PNP
Scale F1, F2, F3 1.0000
Display update Every 1 second
Time out 1 second
Time unit F1, F2 RPM
Assignment of the slave pointer To F1
Assignment for limit value 1 1st upper limit value of F1
Assignment for limit value 2 2nd upper limit value of F1
Output logic for digital output Both outputs as n.o. contacts
Decimal point F1, F2, F3 No decimal point
Assignment of basic display No reset after 15 seconds
Program protection code No code set
Assignment for the function key Function key not assigned
Output characteristics of Only responds on drop below
lower limit value Set value
Option Baud rate 4800 Baud
Parity Even Parity
Stop bit 1 Stop bit
Device address 0
Option Assignment of the analog output Output of F1
Offset for analog output No offset (2 V or 4 mA)
Lower analog limit value 0
Upper analog limit value 4095
6.3 Error messages
Error messages Err 1 and Err 2 Hardware error, must be sent in for repair.
Err 6 Input frequency at tachometer F1 too high.
The error code can be cancelled by pressing the
key.
999999
flashes
Over-range of displays F1, F2, F3.
Can also occur at low frequencies due to unfa-
vourable parameter settings.
Example:
F1 = 100 Hz, bF1 = 0.01, unit = 1/h
100/0.01 * 3600 = 3600 000
Flashing of the numbers 999999 is automatically
cleared after correcting the parameter or raducing
the frequency.
