6.4 Programming lines - overview
Line Default settings Short form
01
Tacho display F1
02
Tacho display F2
03
Tacho display F3
04
Max. hold
05
Limit value 1
06
Limit value 2
10
Separating line
11
Display access status F1
12
Display access status F2
13
Display access status F3
14
Status max. hold
15
Status limit 1
16
Status limit 2
20
Separating line
21
Measuring functions
22
Inverted function
23
Count mode tacho 1
24
Input logic
25
Scale tacho 1
26 Scale tacho 2
27 Calculation of the scale factor
28 Update time F1, F2, F3
29
Time out F1, F2, F3
30
Time unit (F1)
31
Time unit (F2)
32
Assignment of max hold
33
Assignment of limit P1
34
Assignment of limit P2
35
Output logic for digital outputs
36 Decimal point F1
37
Decimal point F2
38
Decimal point F3
39
Assignment of basic display
40
Code
