TA202
38 www.baumer.com
5 Programming mode
This chapter describes the process used to program the device.
On the programming level, it is possible to adjust the operating
parameters. The programming mode is subdivided into three
different programming fields.
1st programming field
In the first programming field, it is possible to access and modify all
the operating parameters. Those operating parameters which are dis-
abled on the operating level are also displayed here. The first program-
ming field consists of 6 lines. (Lines 1 – 4 are not programming lines).
2nd programming field
In the second programming field, the individual operating parameters
can be disabled and enabled for access to the operating level. It is
possible to access disabled operating parameters from the first pro-
gramming field.
3rd programming field
In the third programming field, it is possible to program all machine
related functions and values, as well as the interface parameters.
Key functions
For the individual programming fields, the assignment of keys is the
same. There can be a difference between the key assignment used
on the operating and programming level. For this reason, all functions
are described here in full.
Key
Switches to the next operating parameter on the operating and pro-
gramming mode. For fast run-through, keep the key pressed down.
Key
Switches over between programming and operating mode.
Key
Operating and programming mode: Selects the first or next re-
quired decade. The respective selected decade position flashes.
Key
Operating mode: Deletes the display.
Programming mode: Reset to the value zero. Reset of possible
programmed operating values.
Key
Operating mode: Switches from any optional display to a parameter
in accordance with selection made in line 41.
Programming mode: In conjunction with the key, switches over
to the programming mode.
Key
When this key is pressed, the respective decade position swit-
ches on by one point until the maximum setting value is reached.
