7.3.2 Single Frame Mode
In this mode the camera is captured one frame after AcquisitionStart. Then the acquisition
is stopped.
7.3.3 Multi Frame Mode
In this mode a predened number of frames will be captured after AcquisitionStart. The
AcquisitionFrameCount controls the number of captured frames. Then the acquisition is
automatically stopped.
7.3.4 Acquisition Frame Rate (except cameras with Rolling Shutter sen-
sors)
With this feature Baumer introduces a clever technique to the VEX camera series, that
enables the user to predene a desired frame rate in continuous mode.
For the employment of this mode the cameras are equipped with an internal clock genera-
tor that creates trigger pulses.
Notice
From a certain frame rate, skipping internal triggers is unavoidable. In general, this de-
pends on the combination of adjusted frame rate, exposure and readout times.
