Baumuller DSC Series User Manual

TAM 00682 23
DSC 045-100 07 / 2012
Three-phase synchronous motor English
8.5 Fan connection
Figure 6: pole assignment of the fan
8.6 Control port: Resolver
Pin Signal
Option for
allocation KTY on
encoder socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
cos –
-
-
-
sin –
sin +
-
cos +
-
Ref +
-
Ref –
cos –
-
-
-
sin –
sin +
K –
cos +
K +
Ref +
-
Ref –
Figure 7: pole assignment resolver
contactside mounting box
