8.7 Control port: SRS / SRM 50
(encoder with Hiperface-port from SICK / Stegmann companies)
Pin Signal Option for
allocation KTY on
encoder socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
ref cos
+ 485
-
-
sin
ref sin
– 485
cos
-
Gnd
-
+ U
ref cos
+ 485
K +
K –
sin
ref sin
– 485
cos
-
Gnd
-
+ U
Figure 8: pole assignment SRS / SRM 50
8.8 Control port: SEK / SEL 52
(encoder with Hiperface-port from SICK / Stegmann companies)
Pin Signal Option for
allocation KTY on
encoder socket
View of the contact side of the built-in box
1
2
3
4
5
6
7
8
9
10
11
12
ref cos
+ 485
-
-
sin
ref sin
– 485
cos
-
Gnd
-
+ U
ref cos
+ 485
K +
K –
sin
ref sin
– 485
cos
-
Gnd
-
+ U
Figure 9: pole assignment SEK/ SEL 52
