Installation
Operation Manual Safety I/O Terminals SI4000 / SO4000
Document no.: 5.08009.05 Baumüller Nürnberg GmbH
42
of 82
7.1
7.1 Installation
7.1.1 Safety instructions
Before installing and commissioning the safety I/O terminals please read the chapter
ZSa
fety– from page 15 onward.
7.1.2 Transport and storage
Use the original packaging for transporting or storing the digital safety I/O terminals.
CAUTION!
Note the specified environmental conditions
Please ensure that the digital safety I/O terminals are only transported and stored un-
der the specified environmenta
l conditions (see ZAppendix D - Technical Data– from
page 71 onward).
7.1.3 Mechanical installation
DANGER!
Danger from electricity
Set the bus system into a safe, powered down state
before starting installation, dis-
assembly or wiring of th
e Bus Terminals!
7.1.3.1 Control cabinet
The safety I/O terminals must be installed in a control cabinet or terminal box with IP54
protection class according to IEC 60529 as a minimum.
7.1.3.2 Installation of Bus Terminals on C mounting rails
See ZMounting rail installation– from page 36 onward.
7.1.4 Electrical installation
See ZElectrical installation– from page 37 onward.
