7.1.8 Parameterization
7.1.8.1 SI4000 parameter overview
ON ON ON OFF OFF OFF OFF OFF OFF OFF 7
... ... ... ... ... ... ... ... ... ... ...
ON ON ON ON ON ON ON ON ON ON 1023
WARNING!
Unique safety address
Each address may only be used once within a network!
Dip switch
Address
1 2 3 4 5 6 7 8 9 10
PrmName Meaning Values
S_Address Dip switch address 1 to 1023
Channel 1 Activation of channel 1 active/not active
Channel 2 Activation of channel 2 active/not active
Channel 3 Activation of channel 3 active/not active
Channel 4 Activation of channel 4 active/not active
Sensor test
channel 1
The clock signal for connection Input1+
is checked at connection Input1-
active/not active
Sensor test
channel 2
The clock signal for connection Input2+
is checked at connection Input2-
active/not active
Sensor test
channel 3
The clock signal for connection Input3+
is checked at connection Input3-
active/not active
Sensor test
channel 4
The clock signal for connection Input4+
is checked at connection Input4-
active/not active
Channel 1 and
2
For two-channel evaluation, inputs 1 and 2
must have the same signal states
single-channel evalua-
tion/two-channel evalu-
ation
