Installation
Operation Manual Safety I/O Terminals SI4000 / SO4000
Document no.: 5.08009.05 Baumüller Nürnberg GmbH
46
of 82
7.1
7.1.6.1 Tested devices
The following list contains devices that were tested together with the SO4000 terminal.
The results only apply for the current device hardware version at the time of testing. The
tests were carried out in a laboratory environment. Modifications of these products cannot
be considered here. If you are unsure please test the hardware together with the safety
terminal.
Manufacturer Type Comment
Beckhoff AX5801 TwinSAFE Drive option card: safe restart lock
Beckhoff AX2000 AS option Safe restart lock
Beckhoff KL2964 Three-channel contact extension with feedback
Siemens SIRIUS series S00
3RT1016-1BB42
Contactor
Telemecanique LP1K09 Contactor
Dold LG5929.54/100 Extension module with floating contacts
The tests were carried out as function tests o
nly. The information provided in the respec-
tive manufaturer documentation remains valid.
NOTICE!
Recommended protective circuits
We recommend R/C or diode-based protective circuits for these devices. Varistor-
ba
sed protective circuits should not be used.
5’ 2 Output 2+
6’ Output 2-
7’ 4 Output 4+
8’ Output 4-
NOTICE!
Test pulses
When selecting actuators please ensure that the SO4000 test pulses do not lead to
a
ctuator switching or diagnostic message from the SO4000.
The test pulses of the SO4000 terminal outputs are not configurable and cannot be
switch
ed off.
Clamping point Input Signal
