Measurement type Unit AWHP 4.5
MR
AWHP 6
MR-3
AWHP 8
MR-2
AWHP 11
MR-2
AWHP 11
TR-2
AWHP 16
MR-2
AWHP 16
TR-2
Absorbed electrical pow
er
kWe 0.90 1.38 1.82 2.45 2.45 3.47 3.47
Nominal water flow rate
(ΔT = 5K)
m
3
/h
0.80 1.00 1.36 1.96 1.96 2.53 2.53
Tab.3 Heating mode: outside air temperature +2 °C, water temperature at the outlet +35 °C. Performances in accordance
with EN 14511-2.
Measurement type Unit AWHP 4.5
MR
AWHP 6
MR-3
AWHP 8
MR-2
AWHP 11
MR-2
AWHP 11
TR-2
AWHP 16
MR-2
AWHP 16
TR-2
Heat output kW 3.47 3.74 6.80 10.19 10.19 12.90 12.90
Coefficient of Perform
ance (COP)
3.97 3.37 3.30 3.20 3.20 3.27 3.27
Absorbed electrical pow
er
kWe 0.88 1.11 2.06 3.19 3.19 3.94 3.94
Tab.4 Cooling mode: outside air temperature +35 °C, water temperature at the outlet +18 °C. Performances in accordance
with EN 14511-2.
Measurement type Unit AWHP 4.5
MR
AWHP 6
MR-3
AWHP 8
MR-2
AWHP 11
MR-2
AWHP 11
TR-2
AWHP 16
MR-2
AWHP 16
TR-2
Cooling output kW 3.80 4.69 7.90 11.16 11.16 14.46 14.46
Energy efficiency ratio
(EER)
4.28 4.09 3.99 4.75 4.75 3.96 3.96
Absorbed electrical pow
er
kWe 0.89 1.15 2.00 2.35 2.35 3.65 3.65
Tab.5 Common specifications
Measurement type Unit AWHP 4.5
MR
AWHP 6
MR-3
AWHP 8
MR-2
AWHP 11
MR-2
AWHP 11
TR-2
AWHP 16
MR-2
AWHP 16
TR-2
Total dynamic head at
nominal flow rate
kPa 65 63 44 25 25 — —
Nominal air flow rate
m
3
/h
2680 2700 3300 6000 6000 6000 6000
Power voltage of the out
door unit
V 230 230 230 230 400 230 400
Start-up amperage A 5 5 5 5 3 6 3
Maximal amperage A 12 13 17 29.5 13 29.5 13
Acoustic power - Inner
side
(1)
dB(A) 49 49 49 48 48 48 48
Acoustic power - Outside dB(A) 61 65 67 69 69 70 70
Refrigerant fluid R410A kg 1.3 1.4 3.2 4.6 4.6 4.6 4.6
R410A refrigerant
(2)
tCO
2
e 2.714 2.923 6.680 9.603 9.603 9.603 9.603
Refrigerant connection
(Liquid - Gas)
inch 1/4 - 1/2 1/4 - 1/2 3/8 - 5/8 3/8 - 5/8 3/8 - 5/8 3/8 - 5/8 3/8 - 5/8
Max. pre-charged length m 7 10 10 10 10 10 10
(1) Noise radiated by the enclosure - Test run in accordance with the NF EN 12102 standard, temperature conditions: air 7 °C, water 55 °C
(except for AWHP 4.5 MR: air 7 °C, water 45 °C inner and outer sides)
(2) The quantity of refrigerant in tonnes of CO
2
equivalent is calculated using the following formula: quantity (in kg) of refrigerant x GWP/
1000. The Global-Warming Potential (GWP) of R410A gas is 2088.
3 Technical specifications
