7 Reading out measured values
The measured values are available in the Information menu of the
different PCBs.
Certain parameters are displayed:
according to certain system configurations,
according to the options, circuits or sensors actually connected.
Tab.26 Choosing the menu
Counters Selection
Measured values on circuit A Choose menu EHC-04
Measured values on circuit B Choose menu SCB04-B
Measured values connected to the
operation of the heat pump
Choose menu EHC-04
Tab.27 Values available (X) in the sub-menus EHC-04, SCB04-B
Parameter Description Unit EHC-04 SCB04-B
AM002 "Silent mode" status X
AM010 The current pump speed % X
AM012 Current main status of the appliance.
See
Control system sequence chapter
X X
AM014 Current sub status of the appliance.
See
Control system sequence chapter
X X
AM015 Is the pump running? X
AM016 Flow temperature of appliance. °C X
AM019 Water pressure of the primary circuit. bar X
AM027 Instantaneous outside temperature °C X X
AM040 Temperature used for hot water control algorithms. °C X
AM056 Wate flow rate in the system l/min X
AM091 Seasonal mode active (summer / winter)
0: Winter
1: Frost protection
2: Summer neutral band
3: Summer
X X
AM101 Internal system flow temperature setpoint X
CM030 Measure of the Room temperature of the zone °C X X
CM040 Measure Zone Flow Temperature or DHW
temperature
°C X
CM060 Current Pump speed of zone % X
CM120 Zone Current Mode:
0 =Scheduling
1 =Manual
2 =Antifrost
3 =Temporary
X X
CM130 Current activity of the zone:
0 =Anti frost
1 =Reduced
2 =Comfort
3 =Anti legionella
X X
CM190 Wished room temperature setpoint of the zone °C X X
CM210 Current Outside Temperature of the zone °C X X
7 Reading out measured values
