3.3 Dimensions and connections
3.3.1 Domestic hot water tank dimensions
Fig.2 SPC Split 150 WH
MW-2000611-1
500
250
800
1225
1273
175
292
388
566
548
168
138
440
230
4
3
1 2
1 Domestic hot water outlet
2 Domestic cold water inlet
3 1/4” refrigeration connection
4 3/8” refrigeration connection
3.3.2 Outdoor unit dimensions
Dimensions in mm
3.3.3 Control panel dimensions
Dimensions in mm
Fig.3
MW-4000104-1
241 776
530
16
838
546
62
Fig.4
MW-4000105-3
86
86
20
Opt ModeHybrid Mode
