5 Before installation
5.1 Position of the data plates
The data plates must be accessible at all times, they are used to identify
the product and give the following information:
Appliance type,
Serial number,
Electrical power supply.
5.2
Choice of the location
5.2.1
Selecting the location of the domestic hot water tank
To ensure good accessibility and facilitate maintenance of the domestic
hot water tank, its selected position should comply with the minimum
dimensions indicated by the manufacturer.
Fig.8
MW-2000383-2
Fig.9
MW-2000384-2
6
6
0548
566
580
560x580
