1. Choose the location of the domestic hot water tank keeping in mind
the dimensions indicated opposite.
2. Choose a room that complies with the following specifications:
A room connected to an external wall to facilitate the connection
between the domestic hot water tank and the outdoor unit,
A dry room that is sheltered from frost and maintained at a
temperature no lower than 7 °C,
Avoid rooms that are exposed to gas, vapour or dust.
3. Observe the IP24 protection rating of the domestic hot water tank,
during installation.
Fig.10
150l
MW-2000651-2
1273
1225
350 mini
75 mini
Fig.11
150l
1745
MW-2000652-1
150 mini
5 Before installation
7740327 - v03 - 03122019 21
