4. Fix the brackets to the domestic hot water tank the correct way round,
using the screws and washers on the domestic hot water tank, while
supporting the appliance to avoid any tipping.
5. Tilt the domestic hot water tank onto its brackets.
6. Attach the domestic hot water tank by inserting the brackets onto the
screws.
7. Fasten the screws.
Fig.29
4
4
MW-2000635-1
Fig.30
90°
5
MW-2000392-2
Fig.31
6
6
MW-2000393-2
7 Installation
32 7740327 - v03 - 03122019
