Preventive Maintenance 15
SIGMA Spectrum Infusion System Pump Operating Software Version 6.02 and 6.05
Preventive Maintenance For Use With MDL Version 6
NOTE: If the Pump displays a Check Flow screen, press the yes soft key to proceed to the
Infusion Running Screen.
12. Verify that the Pump indicates an UPSTREAM OCCLUSION alarm prior to the infusion
complete message.
13. Release the occlusion by removing the hemostat.
14. Press OK to acknowledge the alarm.
15. Press RUN/STOP to continue to run the infusion until the IV normalizes (air removed from line)
(5-10 seconds).
16. Press RUN/STOP to stop the infusion.
NOTE: In the event of a test failure, confirm failure by repeating the test with a new
(unused) IV set.
17. Record the findings on the Preventive Maintenance Check Sheet.
Flow Rate Accuracy Test
Either Volumetric or Gravimetric methods of collection may be used. Begin to test the flow rate
accuracy with either method by performing the following steps.
To test the flow rate accuracy:
1. Load a primed IV set into the Pump for testing. See “Test Setup.” on page 11.
NOTE: If the “New Patient Yes/No?” prompt appears, press the yes soft key.
2. Verify that the roller clamp is open.
3. Select any Care Area and press OK.
4. Press OK to view the Drug Library.
5. From the Drug Library, select BASIC and then press OK.
6. Select Primary Bag and press OK.
7. For Mode select mL/hr and press OK.
8. Set the Rate to 40 mL/hr and press OK.
9. Set VTBI mL to 20 mL and press OK. (The run time is 30 minutes)
10. Set up the collection cup or graduated cylinder.
NOTE: The collection cup or graduated cylinder should be dry.
11. Press RUN/STOP. Allow the infusion to run until the Pump displays an infusion complete
alarm.
