18 Preventive Maintenance
Manual 41394 SIGMA Spectrum Infusion System
Revision A Preventive Maintenance
18. Press RUN to resume infusion.
The Check Flow screen appears.
19. Press the yes soft key to proceed to the Infusion Running screen.
20. Press RUN/STOP to stop the infusion.
NOTE: In the event of a test failure, confirm failure by repeating the test with a new
(unused) IV set.
21. Record the findings on the Preventive Maintenance Check Sheet.
22. If performing additional tests, ensure to re-prime the IV set to remove any remaining air in line.
Battery Capacity Test
Perform the Battery Capacity Test if a problem is suspected with the Pump’s Battery Module. For
instance, if the charge does not last as long as it should.
NOTE: Prior to starting the test, charge a Standard Battery for a minimum of 12 hours. Charge a
Wireless Battery Module for a minimum of 16 hours.
To test the battery capacity:
1. Plug the AC Power Adaptor into a working wall outlet and verify green LED is lit while plugged
in.
2. Adjust an IV test set in a loop configuration, so as to circulate fluid around the loop.
3. Press ON/OFF to power on the Pump
4. Load the IV set into the Pump following the display prompts. Verify that the IV set is properly
loaded.
NOTE: If the IV set is not properly loaded, the test results will be invalid.
5. Press the options menu soft key.
6. Select User Options and press OK.
7. Select Display Settings and press OK.
8. Select Display Adjust and press OK.
9. Set the Backlight Level to 10 and press OK.
10. Press exit twice to return to the Options screen.
11. Select the Biomed Options and enter the first level Biomed password.
12. Select Pump Testing and press OK.
13. Select Battery Test and press OK.
14. Select Battery Life Test and press OK.
