Preventive Maintenance 19
SIGMA Spectrum Infusion System Pump Operating Software Version 6.02 and 6.05
Preventive Maintenance For Use With MDL Version 6
15. When the “Load tube into pump and push OK to continue” confirmation screen appears, press
OK.
16. Enter or verify 125 mL/hr for Rate and press OK.
17. Turn Low batt (battery) alarm off and press OK.
18. Turn Constant alarm off and press OK.
19. When “Done” is displayed, press OK.
20. If necessary, unplug the Pump’s AC Power Adaptor.
21. Ensure the current battery level indicates a fully charged battery (between 8.0V and 8.3V). If
battery is fully charged, press OK.
The Pump will run until the battery is depleted and will then power off.
22. After the battery is depleted, plug the Pump’s AC Power Adaptor into a powered wall
receptacle or install a fully charged battery.
When the Pump is powered, “Start to dead” and “Low to dead” will be displayed.
Pass criteria for a used battery
Standard Battery Module:
■ ≥6 hours from “Start to dead”
■ ≥31 minutes from “Low to dead”
Wireless Battery Module (WBM):
■ ≥3 hours from “Start to dead”
■ ≥31 minutes from “Low to dead”
Pass criteria after installation of a new battery (less than 30 days old)
Standard Battery Module:
■ ≥8 hours from “Start to dead”
■ ≥31 minutes from “Low to dead”
WBM:
■ ≥4 hours from “Start to dead”
■ ≥31 minutes from “Low to dead”
If the battery capacity is less than the pass criteria, the battery is reaching end of life. See your
Service Manual.
