DS-SERIES OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
28
Type "B" for 115.2K baud rate. The DS71
responds with the new configuration status:
Module 1 Serial Port Configuration :
Port Device
Name
Baud
Rate
Word
Size
Stop
Bits
Parity Xon/
Xmit
Xoff/
Recv
Line
DTR
Drive
RTS
1 EIA-232 115.2K 8 1 None Off Off High High
Exit/Save..….......1 Set Parity...….........5
Set Baud Rate….2 Set Xon/Xoff….......6
Set Word Size….3 RTS Line Driver....7
Set Stop Bits..…..4 DTR Line Driver...8
Enter Request :
Set Word Size by selecting #3, “Set Word
Size.” The DS71 displays the following list
of available word sizes:
1 For 5
2 For 6
3 For 7
4 For 8
Enter the corresponding number for the
desired word size. The DS71 responds with
the new configuration status:
Module 1 Serial Port Configuration :
Port Device
Name
Baud
Rate
Word
Size
Stop
Bits
Parity Xon/
Xmit
Xoff/
Recv
Line
DTR
Drive
RTS
1 EIA-232 115.2K 8 1 None Off Off High High
Exit/Save..….......1 Set Parity...….........5
Set Baud Rate….2 Set Xon/Xoff….......6
Set Word Size….3 RTS Line Driver....7
Set Stop Bits..…..4 DTR Line Driver...8
Enter Request :
To permanently save configuration changes,
select 1, “Exit/Save,” from the selection
menu, followed by <cr>. The DS71
responds:
Change Host Device to Match NEW Configuration
Before Answering this Request
Save Changes Permanently ? (Y/N) :
