IMPORTANT: This message reminds you to change the serial port
configuration of the host terminal to match the new configuration
changes made to the serial port on the host module. If they do not
match, the DS71 will be unable to interpret the next command, and
you will be unable to access any connected unit. If this happens,
recycle power and reconfigure the unit. Make any necessary changes
to the host device before answering "Save Changes Permanently?"
If you have made necessary changes to the
host device, type "Y" for yes, followed by
<cr>. New configuration changes are stored
permanently in non-volatile memory.
DS71-MD2 From the configuration menu, select #2,
“Serial Port Configuration”, followed by
<cr>. The DS unit asks for the Host Device
number.
Enter Host Device Number (1-2) :
Selecting #1 will give the same results as the
DS71 in the previous section. Selecting 2
will give the following table:
Module 1 Serial Port Configuration :
Port Device
Name
Baud
Rate
Word
Size
Stop
Bits
Parity Xon/
Xmit
Xoff/
Recv
Line
DTR
Drive
RTS
2
Host MODEM
57.6k 8 1 None Off Off High High
Exit/Save.............1 Set Parity...............5
Set Baud Rate.....2 Set Xon/Xoff..........6
Set Word Size.....3 RTS Line Driver...7
Set Stop Bits........4 DTR Line Driver...8
Enter Request :
Select the corresponding number to
configure baud rate, word size, stop bits,
parity.
