TX1500 Manual Combined 1Oct03 PSC Page 23 of 31 Matrix
System Parameters 2
Bump Cameras off
Return to patrol N/A
Startup Actions
Monitors
None in sequence
Return
SYSTEM PARAMETERS 2
Used to program additional settings as follows:
Bump Cameras :
Use to select the keyboards that will cause the current camera to be removed from other monitors when
manually controlled. This is to prevent for example public display store monitors from displaying cameras which
are following a suspect. Use +/- to cycle through options.
Kbd 1, Kbd 2 , Kbd 1 + 2, Kbd 3, Kbd 4, Kbd 1 + 2 + 3 , Kbd 1+2+3+4
Return to patrol :
This is a future feature.
Startup Actions – Monitors:
When the Tx1500 is powered up it sometimes useful if monitors automatically sequence cameras. This option
allows selected monitors to resume sequence should the system power fail and restore. Use +/- to cycle options.
None, 8, 7 8, 6 7 8, 5 6 7 8, 4 5 6 7 8, 3 4 5 6 7 8, 2 3 4 5 6 7 8 , or 1 2 3 4 5 6 7 8.
