RX45Q User’s Manual
17
Internal Connector
Label Function Note Page
AAFP1 Front Panel Audio Connector 5 x 2 header, pitch 2.54mm 37
ATX12V1 ATX Power Connector 2 x 2 header 38
CHA_FAN Chassis Fan Connector 3 x 1 wafer, pitch 2.54mm 39
CPU_FAN1 CPU Fan Connector 4 x 1 wafer, pitch 2.54mm 39
EATXPWR1 ATX Power Connector 12 x 2 header 38
F_PANEL1 System Panel Connector 5 x 2 header, pitch 2.54mm 40
JAMP1 Amplifier Connector 4 x 1 header, pitch 2.54mm 41
JDIO1 Digital I/O Connector 10 x 2 header, pitch 2.54mm 41
SATA1~6 Serial ATA Connectors 1~6 7-pin header 42
SPDIF_O1 Digital Audio Connector 4 x 1 header, pitch 2.54mm 43
SYS_FAN System Fan Connector 3 x 1 wafer, pitch 2.54mm 39
USB5&6,
USB7&8,
USB9&10,
USB11&12
USB 2.0 Connector 5 x 2 header, pitch 2.54mm 44
