RX45Q User’s Manual
40
1.1.31 USB 2.0 Connector (USB5&6, USB7&8, USB9&10, USB11&12)
These connectors are for USB 2.0 ports. Connect the USB/GAME module cable to any of these connectors,
then install the module to a slot opening at the back of the system chassis. These USB connectors comply
with USB 2.0 specification that supports up to 480 Mbps connection speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
The USB module is purchased separately.
