RX45Q User’s Manual
16
1.1.3 Layout Content List
Slots
Label Function Note Page
DIMM_A1 240-pin DIMM slot 1 N/A
DIMM_A2 240-pin DIMM slot 2 N/A
DIMM_B1 240-pin DIMM slot 3 N/A
DIMM_B2 240-pin DIMM slot 4 N/A
PCIEX1 PCI express x1 slot N/A
PCIEX4 PCI express x4 slot N/A
PCIEX16 PCI express x16 slot N/A
PCI1 PCI slot N/A
Jumpers
Label Function Note Page
CLRTC1 Clear CMOS 3 x 1 header, pitch 2.54mm 32
CHASSIS1 Chassis Intrusion Connector 4 x 1 header, pitch 2.54mm 33
COM1 PWR,
COM2 PWR
COM1 Power Setting
COM2 Power Setting
RI/+12V/+5V Select
3 x 2 header, pitch 2.00mm 33
PSON1 AT/ATX Power Mode Select 3 x 1 header, pitch 2.54mm 34
Rear Panel Connector
Label Function Note Page
KBMS1 PS/2 keyboard and mouse 6-pin Mini-Din 35,36
DUALCOM Serial Port Connector D-sub 9-pin, male 35,36
DUAL DVI DVI Connector DVI-I connector with blue color 35,36
LAN1_USB12 RJ-45 Ethernet Connector x 1
USB Connector x 2
Intel 82567LM GbLAN (AMT) 35,36
LAN2_USB34 RJ-45 Ethernet Connector x 1
USB Connector x 2
Intel 82541PI GbLAN 35,36
AUDIO1 Line-in Port, Line-out Port,
Microphone Port,
5.1 Channel Audio I/O (3 jacks) 35,36
To Next Page
