BCM RX45Q - Digital Audio Connector (SPDIF_O1)

RX45Q User’s Manual
39
1.1.30 Digital Audio Connector (SPDIF_O1)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port(s). Connect S/PDIF module
cable to this connector, then install the module to a slot opening at the back of the system chassis.
The S/PDIF module is application demonstration example only.
