1.1.14 PCI Express X16 Slot
This motherboard supports one PCI Express x16 graphic
card that complies with the PCI Express specifications.
The figure shows a graphics card installed on the PCI
Express x16 slot.
1.1.15 PCI Express X4 Slot
This motherboard has one PCI Express x4 slot.
1.1.16 PCI Express X1 Slot
This motherboard has one PCI Express x1 slot.
Onboard DVI (DVI-I & DVI-D)
will be disabled when
PCI-Ex16 card installed.
