RX45Q User’s Manual
22
2. Push down two fasteners at a time in a diagonal
sequence to secure the heatsink and fan assembly in
place.
3. Connect the CPU fan cable to the connector on the motherboard labelled
CPU_FAN1.
Do not forget to connect the fan cables to the fan connectors. Insufficient air
flow inside the system may damage the motherboard components, and
hardware monitoring errors can occur if you fail to plug this connector.
These are not jumpers! DO NOT place jumper caps on the fan connectors.
