8
◎ Analog Output
◎ Serial (RS-232-one way)
F203
Output Mode
1 Stream
2 Stable and auto print
3 Manual Print Mode
4 Accumulate and Print
5 For RS-232 commanding
6 For Modbus commanding
F204
Serial address (RS-485)
00-not used(●Factory set at 00)
00-99 Used
F205
RS-232 Models select
0
BDI-2001/ AD4321
1
BDI-9301
2
IQ-350
3
HB-8210
F 500
Analog Output Data
1 Output 4~20 mA
2 Output 0~+10 V
F 501
Output Mode
1 Same as display
2 GROSS Weight
3 NET Weight
F 502
Loss-in-weight Absolute
Value
0
Not read Absolute
Value
1
BDI-2001B reads
Absolute Value
F 503
Output current when display
ZERO
0.0 through 99.9
● Initial 4.0
(If F 500=1, Normally between 4-20,
If F 500=2, Normally between 0-10)
F 504
Output current at Full Capacity
0.0 through 9.99
● Initial 20.0
(If F 500=1, Normally between 4-20,
If F 500=2, Normally between 0-10)
FL00 Band Rate
1 1200BPS
2 2400BPS
FL01 Output data
1 Same as display
2 GROSS Weight
3 NET Weight
4 TARE Weight
5
GROSS Weight, NET
Weight, TARE Weight
FL02
Output Mode
1 Stream
2 Stable and auto print
3 Manual Print Mode
4 Accumulate and Print
To Next Page
