BEA VIO-M1 - Page 2

2
2
1
MIN
VIO-M1
ON
OFF
MAX
1
ADJUSTMENTS
Apply the mounting template.
Drill 1 hole for the cable and
pull it through.
Drill 2 holes for the screws.
Fix the sensor firmly and
connect the cable.
ANGLE
2.2 m
2.2 m
FIELD SIZE
DIP 1
DETECTION MODE
DIP 2
OUTPUT CONFIG.
DIP 3
PRM-MODE
DIP 4
IMMUNITY FILTER
bidirectional
unidirectional
NO
NC
for PRM*
normal
high
normal
*PRM= persons with reduced mobility
DIP 1 needs to be ON for this function
field size: max
vertical angle: 30°
2.2 m
2.2 m
MOUNTING & WIRING
COM
NO-NC*
12-24 V
DIP-SWITCH
DOOR CONTROLLER
Mount the sensor securely.
* Depending on OUTPUT
CONFIGURATION settings
