8.1 - FREQUENT OPERATIONS
Before carrying out the following operations, connect
the probe to the unit at least through the gray cable
Ch.1 and insert the probe into the vagina or anus
(in the case of anal probe). For the EVO and
BIOFEEDBACK programs, in order to reduce
environmental electrical interference on the EMG
signal, it is also necessary to apply a transcutaneous
adhesive electrode in correspondence with a bone
prominence (e.g. iliac crest) (§ 7.3) and connect it,
using the cable blue, at the EMG-Ref ㉕ entrance.
8.1.1 Switch-ON the unit
Press for 2 seconds the button integrated in the
knob ①.
8.1.2 Switch-OFF the unit
Press for 2 seconds the button integrated in the
knob ①.6The6unit6 will6also6turn-OFF6if the session
does not start in 5 minutes.
8.1.3 Select a program
Touch one of the 6 rectangular areas at the lower
side of the display (⑰,6⑱,6⑲,6⑳,6o).
The label of the selected program will appear in
reverse.
Tthe last used program will be automatically
loaded, when the unit will be switched-ON.
8.1.4 Select the type of probe in use
By touching the area ⑧, you can select the wave-
shape according to the type of the probe in use:
•
the simple impulse ( ) for the probes with ring-
like electrodes.
•
the alternated pulse ( ) for the probes with
lateral electrodes.
The choice of the type of probe used in the last
session, will be automatically loaded when the unit
is switched-ON.
8.1.5 Set the stimulation level
If a program providing electrical stimulation has
been selected (URGE-STRE-MIX-PAIN-EVO), after
connecting and positioning the probe, tap the area
0
mA
⑦, then turn the knob clockwise to feel a strong
and comfortable level of stimulation. After adjusting
