MEGA3 NFPA Medical Gas Notification System
4107 9016 59.03
12.00in
(30.5cm)
7.50in
(19.1cm)
Digital I and II Alarm from Chemetron
A
F
GAS SENSOR
8.38in
(21.3cm)
11.13in
(28.3cm)
Line Pressure Alarms from Medaes,
Ohmeda, or Ohio
GAS SENSOR
F
A
8.38in
(21.3cm)
8.38in
(21.3cm)
Line Pressure Alarms from Medaes,
Ohmeda, or Ohio
A
F
GAS SENSOR
8.38in
(21.3cm)
14.44in
(36.7cm)
Line Pressure Alarms from BeaconMedaes, Medaes,
Ohmeda, or Ohio
GAS SENSOR
F
A
12.00in
(30.5cm)
15.00in
(38.1cm)
TA1 Master Retrofit
A
B
B
F
